FULLY AUTONOMOUS 6 AXIS 20L AGRICULTURE SPRAYING DRONE
This product is not a toy and is not suitable for children under the age of 18. Only for professional usage. The operator must have some flight experience.
The 6-Axis Agricultural Drone with a 20L tank can spray 10 hectares per hour on average.
You have strong GPS signals after calibrating the Compass.
The drone remote control system gives you the possibility to mark certain areas with Google Maps support.
The drone is capable to fly back to the recorded break point and turn on the nozzle to continue the job automatically, if the battery or the tank level is low.
Spread Size | LÂ 2050 x W 1950 x H 750 MM |
Folded Size | LÂ 1170 x W 1070 x H 750 MM |
Aluminum Box Size / Weight | 1050*950*850mm/25kgs |
Net Weight | 25.40 kgs |
Take-off Weight | 48 kgs |
Â
Model | 6 Axis20L 3WWDZ-20A |
Pesticide Tank | 20L |
Flying Time | 10-25min |
Flying Radius | 1000m |
Flying Height | 0-20m |
Flying Speed | 3-8m/s |
Work Temperature | -20~40°C |
Work Humidity | 0~90% |
Spray Speed | 0-8m/s |
Spray Width | 5-8m/s |
Nozzle No. | 6 pcs |
Spray Flow | 5L/min |
Spray Efficiency | 6-12 Hectare/hour |
Wind Resistance | 10m/s |
Motor | Brushless |
Motor KV | 110 （r/min）·V |
Motor rating | 5000W |
Power motor model | X9 PULS |
Propeller | Carbon Fiber |
Type of satellite receiver | GPS |
Obstacle avoidance Sensing range | 3m Obstacle Diameter>=2.5cm |
Obstacle avoidance direction | Front |
Protection grade | IP56 |
Battery / Quantity | 14S 20000mah*2 |
Battery Voltage | 51.8V-60.9V |
Charger | 3000W |
Charger input voltage | 220V （110-240V) |
Charger output voltage | 60V |
Charger output current | 55A |
Toolkit | Maintenance/Repair Tools |
